Anti-static Filter Bag

Contact

Surface resistance(Ω.cm): 108 -103
Good Temperature-Resistance. Max. Temp. 150℃
Material Weight: 100-600gsm
Types:blending type , square type, stripe type
High Filtration Efficiency: reach to 99.5%
Antistatic Filter bag is widely used in flour, chemical and coal industries. Vifico® provide the filter bags with excellent performance of anti-static. We can offer blending type , square type, stripe type for your choices. The customized service can also be provided.

Bag life extended due to significant reduction of fatigue damage to the bags due to bag to cage impact.

Quantity :

Details Content

Main Types of Anti-static Filter Bag:

1.PE (polyester)
2.PP (polypropylene)
3.Special need also be acceptable

Specification of Anti-static Filter Bag:

Material : 100% Anti-static polyester staple fiber
2. Surface resistance(Ω.cm): 10³-10⁸
3. Scrim: with Anti-static polyester filament yarn
4. Diameter:>100 mm
5. Weight:300 -600 g/m² ±10%
6. Temperature (°C/°F): Continue: 130/266, Instant: 150/302

Features of Anti-Static Filter Bag:

High Filtration Efficiency: reach to 99.5%
2. Excellent Anti-Abrasion
3. Stable working time: up to more than 4000 hours. Could be used cyclically
4. High quality and economical
5. Can be customized

Physical Properties and Chemical Properties:

Weight（gsm）	300 -600 g/m² ±10%
Diameter(mm)	>100mm
Finish treatment	Singeing, Calendering, Heat setting
Air permeability(L/m².s)	200-300
Tensile strength(N/5cm)	warp	≥1100
	weft	≥1500
Tensile elongation(%)	warp	≤35
	weft	≤60
Heat shrinkage(%)	warp	≤1.5
	weft	≤1.0
Temperature(°C/°F)	Continue	130
	Instant	150
Anti-acid	Middle
Anti-alkali	Middle
Anti-abrasion	Excellent
hydrolysis stability	Middle
